O'Day 32 Yacht: Specifications and Standard Equipment (1977)

HIGHLIGHTS

• Diesel engine 2:1 reduction gear complete
• Mainsail complete with 2 sets of reef points
• Working Jib
• 5" Fabric berth cushions main cabin; 4" cushions other berths
• Curtains for both cabins
• 2 self-contained heads
• SS bow pulpit
• SS stern pulpit
• SS stanchions with lifelines
• 2-burner alcohol stove
• Wheel steering with 24" SS destroyer wheel
• 2 #10 Barient halyard winches
• 2 #21 2-speed Barient jib sheet winches
• 2 Standard Barient winch handles
• Teak cabin hand rails (both cabins)
• Bilge pump–hand
• Electric outlet, dockside 110 volt complete with 25' wire cord
• Cold water pressure system
• Shower
• Lightning ground
• Gate valve on all thru-hull fittings below waterline
• Jiffy reefing V-berth cushion

DECK

• Flush bow anchor, chain and rope storage compartment with overboard drain
• Mast stepped through deck
• 2 sliding hatches (main & aft cabin)
• 1 bow cleat
• 2 bow chocks
• 2 stern cleats
• Flush forward hatch
• All hardware non-corrosive or SS Non-skid deck
• 2 large cockpit drains
• Two-tone deck color
• All colors molded in
• 2 cockpit seat lockers (lockable)
• 4 fixed windows in main cabin
• 1 opening window in head
• 2 fixed windows in aft cabin
• 2 opening windows in transom
• 2 deck port lights over forward V-berth
• Teak toe rails
• 2 Genoa/Jib cleats
• Balsa wood deck core where necessary
• Rich, oiled teak woodwork

INTERIOR

• Folding galley counter
• Two-tone interior liner pan
• Engine room access through cockpit seat lockers and aft cabin
• Recessed floor pans for carpet Hull liner with foam backing
• Sleeping for 6 … 2 in forward V-berths, 1 in each settee in main cabin. 2 in double berth in aft cabin
• 6'5" headroom in main cabin 6'1" headroom in aft cabin
• Fully enclosed head with ample storage compartments
• 3 hanging lockers (1 between V-berth and main cabin, 1 in aft cabin and 1 wet locker behind head)
• 40 gallon water tank
• 28 gallon fuel tank
• 2 structural fiberglass pans
• Formica counter and table tops throughout
• Galley complete with SS sink, large icebox with drain and area for stove
• Ample storage drawers and compartments in all 3 cabins
• All hardware non-corrosive or SS Folding double leaf table Real teak wood, oiled 2 coats
• Teak sea rails around all counter tops
• 12 volt electrical system with running lights, mast light, twelve interior cabin lights. 1 engine room light, and fused switch panel complete with heavy duty marine battery
• Textured fiberglass headliners in all 3 cabins

HULL

• Inboard rudder behind skeg
• Fiberglass C/B lead ballasted with cockpit pendant control via enclosed winch system One-piece fiberglass molded hull and keel
• Vinyl gunwale guard (2-piece)
• All hardware non-corrosive or SS
• All colors molded in
• Inside lead ballast on CB, external on fixed keel model

MAST AND BOOM

• Anodized mast and boom
• SS rigging with swaged terminals and turnbuckles
• Finest dacron running rigging
• Topping Lift
• 2 Halyard cleats
• Four-part mainsheet system

O'Day 32 Yacht Specifications (1977)

L.O.A.	31'-7" (9.63M)
L.W. L.	27'-31/2" (8.32M)
Beam	10'-6" (3.20M)
Draft (centerboard model)	3'-4"/7'-1" (1.02M-2.16M)
Draft (keel model)	4'-6" (1.37M)
Sail area (100% foretriangle)	470 sq. ft. (43.66 sq. M)
Displacement	11,000 lbs. (4944K)
Ballast (centerboard)	3880 lbs.
Ballast (keel)	3575 lbs.
Mast above water	43'-6" (13.26M)

O'Day 32 Rig Measurements

I (Foretriangle height)	39.0' (11.89M)
J (Foretriangle base)	12.75' (3.89M)
P (Mainsail luff)	34.0' (10.36M)
E (Mainsail foot)	13.0' (3.96M)

O'Day

A Bangor Punta Company

Fall River, MA 02722

Additional manufacturing facilities in Costa Mesa, California.
